Files

glasses-shamrocks.stl

218136 bytes. Updated March 17, 2012.

glasses-shamrocks.scad

2458 bytes. Updated March 17, 2012.

glasses-arm.scad

633 bytes. Updated March 17, 2012.

glasses-arm.svg

2142 bytes. Updated March 17, 2012.

This work is licensed Creative Commons - Attribution.

Description

Get out your best green filament and get festive!

These 8-bit glasses print all in one piece - arms and all! The corners of the frames are tacked down with “mouse ears” in the shape of shamrocks, so you’re all set for your St. Patrick’s Day celebrations!

The default size should fit most people, but feel free to scale the design, or play with it in OpenSCAD and make your own stylish variation!

These glasses are inspired by the “5DPI” glasses design by Dzmitry Samal: http://www.dzmitrysamal.com/5dpi.html

Instructions

The STL is sized to fit my face, so this is a fairly large print. It prints really well on my Replicator, though!

1. Scale to fit: head size, printer volume, target species (great for pets!)
2. Print!
3. For comfort, sand the edges that will touch you: the inside of the nosepiece and the parts of the arms that touch the ears.
4. Not in the mood for shamrocks? They help hold down the corners while the glasses are printing, but you can easily peel them off when you’re done.

Want to make alterations? It’s pretty easy!

• The “bits” for the frames are defined in a little array at the top of glasses-shamrock.scad
• The arms were drawn in Inkscape and exported to glasses-arms.scad using the Inkscape to OpenSCAD Polygon plugin ( https://github.com/martymcguire/inkscape-openscad-poly )
• The “shamrock” shape is defined in the left mouse ear module and then flipped for you automatically.

Files

change.stl

126079 bytes. Updated March 4, 2012.

change.svg

4953 bytes. Updated March 4, 2012.

change.scad

2859 bytes. Updated March 4, 2012.

This work is licensed Creative Commons - Attribution.

Description

The Baltimore Node is pleased to have taken part in the creation of the cover for Urbanite Magazine’s March 2012 “Change Makers” issue.

The file was designed in Inkscape and OpenSCAD and printed on MakerBot Thing-O-Matic #5564. Dozens of photos were taken during the build and then combined into the final cover image by the excellent people at Urbanite.

You can find the online archive for the issue here: http://www.urbanitebaltimore.com/baltimore/IssueArchives?issue=1469643

Other issues of the Urbanite are here: http://www.urbanitebaltimore.com/

If you’re in the Baltimore/DC area, check out the Baltimore Node Hackerspace! http://baltimorenode.org/

Instructions

Print and enjoy.

If you print it upright (as we did, for time-lapse purposes), you’ll likely get some stringing.

Change is messy. :)

This object was made by:

1. Creating text and baseline shape in Inkscape and combing it all into a single path.
2. Exporting the path to OpenSCAD polygons using this Inkscape plugin: https://github.com/martymcguire/inkscape-openscad-poly/
3. Adding a call to “linear_extrude(..)” in the resulting OpenSCAD file.
